    Rivian R1T & R1S Wheel & Tire Fitment Guide

    Everything you need to know about your Rivian R1T & R1S Wheels.

    Jump to: OEM Rivian R1S & R1T | Aftermarket Rivian R1S & R1T | View Rivian R1S & R1T Wheel Gallery Here



    OEM Rivian R1T & R1S



    20 inch Rivian R1S R1T All Terrain

    20" Rivian R1T & R1S All Terrain Wheel

    Wheel Size: 20x8.5"
    Wheel Offset: +48
    PCD: 5x5.5"
    Lug Bolt: 14mm x 1.5mm [22mm socket]
    Lug Bolt Torque Spec: 140 ft-lbs / 190 Nm
    Centerbore: 64.1 mm
    Weight: 35.7 lbs
    Rivian Option: $2,500 with a Rivian R1T & R1S.
    Tire Spec: Pirelli Scorpion All Terrain Plus - 275/65-20 118H XL RIV

    20 inch Rivian R1S R1T All Terrain Bright

    20" Rivian R1T & R1S All Terrain Bright Wheel

    Wheel Size: 20x8.5"
    Wheel Offset: +48
    PCD: 5x5.5"
    Lug Bolt: 14mm x 1.5mm [22mm socket]
    Lug Bolt Torque Spec: 140 ft-lbs / 190 Nm
    Centerbore: 64.1 mm
    Weight: TBD
    Rivian Option: $2,500 with a Rivian R1T & R1S.
    Tire Spec: Pirelli Scorpion All Terrain Plus - 275/65-20 118H XL RIV

    20 inch Rivian R1S R1T All Terrain Dark

    20" Rivian R1T & R1S All Terrain Dark Wheel

    Wheel Size: 20x8.5"
    Wheel Offset: +48
    PCD: 5x5.5"
    Lug Bolt: 14mm x 1.5mm [22mm socket]
    Lug Bolt Torque Spec: 140 ft-lbs / 190 Nm
    Centerbore: 64.1 mm
    Weight: TBD
    Rivian Option: $3,500 with a Rivian R1T & R1S.
    Tire Spec: Pirelli Scorpion All Terrain Plus - 275/65-20 118H XL RIV

    21 inch Rivian R1S R1T Road

    21" Rivian R1T & R1S Road

    Wheel Size: 21"
    Wheel Offset: +48
    PCD: 5x5.5"
    Lug Bolt: 14mm x 1.5mm [22mm socket]
    Lug Bolt Torque Spec: 140 ft-lbs / 190 Nm
    Centerbore: 64.1 mm
    Weight: TBD
    Rivian Option: No Charge with a Rivian R1T & R1S.
    Tire Spec: Pirelli Scorpion Verde All Season - 275/55-21 116H XL RIV

    22 inch Rivian R1S R1T Sport Bright

    22" Rivian R1T & R1S Sport Bright

    Wheel Size: 22"
    Wheel Offset: +48
    PCD: 5x5.5"
    Lug Bolt: 14mm x 1.5mm [22mm socket]
    Lug Bolt Torque Spec: 140 ft-lbs / 190 Nm
    Centerbore: 64.1 mm
    Weight: TBD
    Rivian Option: $2,500 with a Rivian R1T & R1S.
    Tire Spec: Pirelli Scorpion Zero All Season - 275/50-22 116H HL RIV

    22 inch Rivian R1S R1T Sport Dark

    22" Rivian R1T & R1S Sport Dark

    Wheel Size: 22"
    Wheel Offset: +48
    PCD: 5x5.5"
    Lug Bolt: 14mm x 1.5mm [22mm socket]
    Lug Bolt Torque Spec: 140 ft-lbs / 190 Nm
    Centerbore: 64.1 mm
    Weight: TBD
    Rivian Option: $3,500 with a Rivian R1T & R1S.
    Tire Spec: Pirelli Scorpion Zero All Season - 275/50-22 116H HL RIV

    Aftermarket Rivian R1S & R1T Wheels Offered by EV Sportline:

    Jump to: OEM Rivian R1S & R1T | Aftermarket Rivian R1S & R1T

    We engineer our wheels to fit within the factory parameters of your Rivian R1S & R1T, which means our wheels use the following:

    • The factory Rivian lug nuts
    • The factory Rivian center caps
    • The factory or aftermarket tires
    • The factory Rivian TPMS tire pressure sensors

    The fact that we have designed all our wheels to fit all the factory hardware alleviates the need to fiddle with aftermarket lug nuts, branded center caps and different tire sizes. All you need to do is swap the wheels!

    20 inch Rivian R1S R1T Forged Wheels

    20" Team 1EV Precision Forged R500 Directional Aero Wheel

    Wheel Size: 20x9
    Wheel Offset: +38mm
    PCD: 5x5.5"
    Lug Bolt: 14mm x 1.5mm [22mm socket]
    Lug Bolt Torque Spec: 140 ft-lbs / 190 Nm
    Centerbore: 64.1 mm
    Weight: 35.4 lbs
    Price: Starting at $5,800
     Load Rating: 1,200 kg/2,640 lbs
    20 inch Rivian R1S R1T Forged Wheels

    20" Team 1EV Precision Forged R600 Overland XL Wheel

    Wheel Size: 20x8.5"
    Wheel Offset: +48mm
    PCD: 5x5.5"
    Lug Bolt: 14mm x 1.5mm [22mm socket]
    Lug Bolt Torque Spec: 140 ft-lbs / 190 Nm
    Centerbore: 64.1 mm
    Weight: 31.9 lbs
    Price: Starting at $3,995
     Load Rating: 1,150 kg/2,530 lbs
    20 inch Rivian R1S R1T Forged Wheels

    20" Team 1EV R800 Overland XL Wheel

    Wheel Size: 20x8.5"
    Wheel Offset: +48
    PCD: 5x5.5"
    Lug Bolt: 14mm x 1.5mm [22mm socket]
    Lug Bolt Torque Spec: 140 ft-lbs / 190 Nm
    Centerbore: 64.1 mm
    Weight: 33 lbs
    Price: Starting at $2,495
     Load Rating: 1,150 kg/2,530 lbs

    20 inch Rivian R1S R1T Forged Wheels

    20" Team 1EV R1000 Overland XL Wheel

    Wheel Size: 20x8.5"
    Wheel Offset: +48mm
    PCD: 5x5.5"
    Lug Bolt: 14mm x 1.5mm [22mm socket]
    Lug Bolt Torque Spec: 140 ft-lbs / 190 Nm
    Centerbore: 64.1 mm
    Weight: 35 lbs
    Price: Starting at $2,495
     Load Rating: 1,150 kg/2,530 lbs

    20 inch Rivian R1S R1T Forged Wheels

    20" Team 1EV Precision Forged R80B RMaxx Beadlock Off-road Wheel

    Wheel Size: 20x8.5"
    Wheel Offset: +40mm
    PCD: 5x5.5"
    Lug Bolt: 14mm x 1.5mm [22mm socket]
    Lug Bolt Torque Spec: 140 ft-lbs / 190 Nm
    Centerbore: 64.1 mm
    Weight: 33 lbs
    Price: Starting at $4,995
     Load Rating: 1,150 kg/2,530 lbs
    20 inch Rivian R1S R1T Forged Wheels

    21" Team 1EV Precision Forged R500 Directional Aero Wheel

    Wheel Size: 21x9
    Wheel Offset: +38mm
    PCD: 5x5.5"
    Lug Bolt: 14mm x 1.5mm [22mm socket]
    Lug Bolt Torque Spec: 140 ft-lbs / 190 Nm
    Centerbore: 64.1 mm
    Weight: TBD
    Price: Starting at $6,000
     Load Rating: 1,200 kg/2,640 lbs
    //
